A/C Component Location Index

A/C Component Location Index



SERVICE VALVE
(LOW-PRESSURE SIDE)SERVICE VALVE
(HIGH-PRESSURE SIDE)COMPRESSOR
Replacement,
Clutch Check,
Clutch Overhaul,
Thermal Protector Check,
Thermal Protector Replacement,
Relief Valve Replacement, RECEIVER/DRYER
Desiccant replacement, CONDENSER
(With built-in receiver/dryer)
Replacement, EVAPORATOR CORE
(Built-in the heater unit)
Replacement, NOTE: LHD type is shown, RHD type is similar.SIGHT GLASS



BLOWER MOTOR RELAY
(Located backside of the
under-dash fuse/relay box)
Test, A/C PRESSURE SWITCHRADIATOR FANCONDENSER FANNOTE: LHD type is shown, RHD type is similar.RADIATOR FAN RELAY,
CONDENSER FAN RELAY,
COMPRESSOR CLUTCH RELAY
(Located in the under-hood fuse/relay box)
Test,
