Cylinder Head Assembly Component Location Index (L12A/L13A)

Cylinder Head Assembly Component Location Index



CYLINDER HEAD COVER
Removal,
Installation, CAM CHAIN
GUIDECRANKSHAFT PULLEY
Replacement,
CRANKSHAFT
PULLEY BOLT
Replacement,
CHAIN CASEO-RINGIDLER PULLER
(With A/C COMPRESSOR)CAM CHAIN
Removal,
Installation,
CAMSHAFT SPROCKET
Removal,
Installation, CAM CHAIN
TENSIONER SLIDERCAM CHAIN
TENSIONERHEAD COVER
GASKETCYLINDER HEAD PLUG



THERMOSTAT
Replacement,
Inspection, EXHAUST GAS RECIRCULATION
(EGR)/PASSAGE ASSEMBLY
Installation, O-RINGDOWEL PINCYLINDER HEAD BOLT
Inspection, THERMOSTAT HOUSINGGASKETCYLINDER HEAD
GASKET



INTAKE VALVE GUIDE
Replacement, CYLINDER HEAD
Removal,
Inspection,
Installation, EXHAUST VALVE
Removal,
Installation, INTAKE VALVEEXHAUST
VALVE SEALSPRING RETAINERVALVE KEEPERSVALVE SPRING
SEATEXHAUST VALVE
GUIDETDC SENSORO-RINGCAMSHAFT
THRUST
COVERINTAKE VALVE
SPRING EXHAUST VALVE
SPRINGINTAKE VALVE SEALROCKER ARM ASSEMBLY
Overhaul,
Inspection, O-RINGCAMSHAFT
Inspection,
