C-02
|
(3)
|
Room lamp
|
C-04
|
(2-R)
|
Side-airbag module (squib) (RH)
|
C-05
|
(3-B)
|
Seat heater (RH)
|
C-06
|
(2-B)
|
Curtain air bag module (squib) (RH)
|
C-07
|
(3)
|
Rear door switch (RH)
|
C-08
|
(2-B)
|
Curtain air bag module (squib) (LH)
|
C-09
|
(1)
|
Luggage compartment lamp (+)
|
C-10
|
(1)
|
Luggage compartment lamp (-)
|
C-12
|
(3)
|
Rear door switch (LH)
|
C-13
|
(5-B)
|
Fuel pump and gauge unit
|
C-14
|
(10)
|
Instrument panel wiring harness and rear door wiring harness (LH) combination
|
C-15
|
(2-B)
|
Rear wheel speed sensor (LH)
|
C-16
|
(2-B)
|
Rear wheel speed sensor (RH)
|
C-17
|
(3)
|
Front door switch (LH)
|
C-18
|
(2-B)
|
Seat belt pre-tensioner (LH)
|
C-19
|
(2-Y)
|
Side impact sensor (LH)
|
C-20
|
(2-R)
|
Side-airbag module (squib) (LH)
|
C-21
|
(3-B)
|
Seat heater (LH)
|
C-22
|
(2)
|
Seat belt switch (LH)
|
C-23
|
(1)
|
Parking brake switch
|
C-24
|
(4)
|
Oxygen sensor (rear) <134, 3A9, 135, 4A9>
|
C-25
|
(8-B)
|
Seat heater switch (LH)
|
C-26
|
(4-B)
|
G and yaw rate sensor <with ASC>
|
C-27
|
(2)
|
Seat belt switch (RH)
|
C-28
|
(12-B)
|
Allshift lever
|
C-29
|
(7)
|
Seat heater switch (RH)
|
C-30
|
(2-Y)
|
Side impact sensor (RH)
|
C-31
|
(2-B)
|
Seat belt pre-tensioner (RH)
|
C-32
|
(3)
|
Front door switch (RH)
|
C-33
|
(10)
|
Instrument panel wiring harness and rear door wiring harness (RH) combination
|
C-34
|
(8)
|
Front wiring harness and roof wiring harness combination
|
C-39
|
(3-B)
|
Rain light sensor <with auto lamp>
|
C-40
|
(6)
|
Capacitor unit <with AS&G>
|
)
