A plastic (resin) wiper arm and blade assembly has been adopted for weight reduction, with emphasis on an integrity appearance of the arm and blade for better looking.
The wiper interval fixed type intermittent wiper has been adopted, thus improving a clear rear view in rainy weather.
The washer tank is commonly shared with the windshield washer.
The initial continuous operation function has been adopted. In this function, the rear wiper performs continuous low-speed operation for 2 to 3 cycles to sweep the raindrops away from the rear screen after the rear wiper switch is turned on, and then proceeds with the intermittent operation.
The washer-linked wiper function* has been introduced. The washer fluid can be injected without operating the wiper optionally. When the ignition switch is turned ON with the washer switch ON, the washer motor operates but the wiper does not.
note
For details on operation, refer to GROUP 54B, Function and Control by ECUs of LIN .
*: The washer-linked wiper function can be enabled or disabled optionally. Refer to GROUP 54B, Customise Function .
)
