Item
|
Specification
|
Transmission model
|
F5MGA-1-30
|
F5MGA-1-33
|
F5MGB-1-61
|
Engine model
|
134
|
135
|
4G1
|
Transmission type
|
5-speed forward, 1-speed reverse
|
Transmission gear ratio
|
1st
|
3.308
|
3.308
|
3.538
|
2nd
|
1.913
|
1.913
|
1.913
|
3rd
|
1.258
|
1.258
|
1.344
|
4th
|
0.943
|
0.943
|
1.027
|
5th
|
0.763
|
0.763
|
0.833
|
Reverse
|
3.231
|
3.231
|
3.357
|
Final reduction ration
|
4.353 <Vehicles without AS&G system>
4.158 <Vehicles with AS&G system>
|
4.158 <Vehicles without AS&G system>
3.842 <Vehicles with AS&G system>
|
3.737
|
Transmission oil
|
Specified lubricants
|
DiaQueen NEW MULTI GEAR OIL API classification GL-3,
SAE 75W-80 or DiaQueen WIDE GEAR OIL G-1 or Castrol/Burmah gear oil BOT328 (or exact equivalents)
|
DiaQueen WIDE GEAR OIL G-1 or Castrol/Burmah gear oil BOT328 (or
exact equivalents)
|
Quantity L
|
1.75
|
)
