For adoption of the under cover integrated with the front bumper assembly, remove the six front bumper clips, and lift the under cover part of front bumper assembly downward.
|
|
1.Remove the six front bumper clips shown in the figure.
|
|
2.Lift the under cover part of front bumper assembly downward.
|
|
|
Do the position of shift drums for sensor change.
|
|
- Set the "A" and "B" parts of the drum position sensor as shown.
- Insert two dowel pins (5 mm x 35 mm) into the both tap holes M6.
- Install the drum position sensor with the aid of the both dowel pins.
- In case of a bigger insertion force than 30 N re-do the sensor change procedure with the M.U.T.-III again.
- Remove the both dowel pins, insert the bolts (M6 x 18) and tighten them with 6.0 ± 2.0 N·m.
|
|
|
Coat the shift actuator mounting surface of the transmission case with the specified sealant.
|
|
|
Specified sealant: Loctite 518 or exact equivalent
|
|
|
1.Tighten the clutch actuator mounting bolts temporarily at the point where the clutch actuator push rod contacts with the mechanical release unit.
|
|
2.Gently depress the clutch actuator further 4 mm to the arrow direction from the point where the push rod contacts with the mechanical release unit.
| note |
The depression amount should be measured by using a scale.
|
3.Tighten the mounting bolts to the specified torque.
Tightening torque: 10 ± 1 N·m
|
)
)
)
)
)
