| No. |
Standard measurement point |
Hole shape |
Size mm |
| 23 |
Front pillar positioning notch (upper) |
- |
- |
| 24 |
Front pillar positioning notch (lower) |
- |
- |
| 25 |
Roof side rail positioning notch (front) |
- |
- |
| 26 |
Side sill positioning notch (front) |
- |
- |
| 27 |
Centre pillar positioning notch (upper) |
- |
- |
| 28 |
Centre pillar positioning notch (lower) |
- |
- |
| 29 |
Roof side rail positioning notch (rear) |
- |
- |
| 30 |
Side sill positioning notch (rear) |
- |
- |
| 31 |
Quarter panel positioning notch (upper) |
- |
- |
| 32 |
Quarter panel positioning notch (lower) |
- |
- |
| No. |
Standard measurement point |
Hole shape |
Size mm |
| 43 |
Centre of floor console bracket mounting hole |
Round |
8 |
| 44 |
Body centre point of rear floor |
- |
- |
)
)
)
)
)
)
)
)
)
)
| No. |
Standard measurement point |
Hole shape |
Size mm |
| 11 |
Centre of rear shock absorber mounting hole |
Round |
22 |
| 44 |
Body centre point of rear floor |
- |
- |
| 45 |
Centre of rear end trim mounting hole |
Round |
8.5 |
| 46 |
Tip of instrument panel bracket centre (Body centre point) |
- |
- |
| 47 |
Centre of front deck crossmember mounting hole (upper) |
Round |
10.5 |
| 48 |
Centre of front deck crossmember mounting hole (lower) |
Round |
10.5 |
)
)
)
)
)
