Fuel and Emissions System Description - Wiring Diagram: L12A4 and L13A6 (5MT)

Fuel and Emissions System Description - Wiring Diagram: L12A4 and L13A6

ECM Circuit Diagram (cont'd)

L12A4, L13A6 engines (LHD model)

1234567891011121314151617G101ENGINE
WIRE HARNESSENGINE
COMPARTMENT
WIRE
HARNESS

ENGINE WIRE
HARNESSENGINE COMPARTMENT
WIRE HARNESS18192021222324252627282930ENGINE WIRE
HARNESS31323334

24P JUNCTION
CONNECTOR (1)PRIMARY HO2S
(SENSOR 1) (2)APP SENSOR
(3)IAT/MAP SENSOR
(4)CMP SENSOR
(6)EVAP CANISTER
PURGE VALVE
(5)ECT SENSOR
(7)VSS (8)2P CONNECTOR
(9)ELD (10)UNDER-HOOD
FUSE/RELAY
BOX (13)^**TEST TACHOMETER
CONNECTOR (12)UNDER-HOOD
FUSE/RELAY
BOX (11)^**UNDER-HOOD
FUSE/RELAY
BOX (14)^**UNDER-HOOD
FUSE/RELAY
BOX (15)^**UNDER-HOOD
FUSE/RELAY
BOX (16)^**THROTTLE
BODY (17)No. 1 REAR
IGNITION COIL
(18)No. 2 REAR
IGNITION COIL
(19)No. 3 FRONT
IGNITION COIL
(20)No. 3 REAR
IGNITION COIL
(21)No. 4 REAR
IGNITION COIL
(22)No. 4 FRONT
IGNITION COIL
(23)No. 4 INJECTOR
(24)No. 3 INJECTOR
(25)KNOCK SENSOR
(26)No. 2 INJECTOR
(27)No. 2 FRONT
IGNITION COIL
(28)ALTERNATOR
(29)No. 1 INJECTOR
(30)No. 1 FRONT
IGNITION COIL
(31)EGR VALVE
(32)CKP SENSOR
(33)VSA MODULATOR-
CONTROL UNIT (34)*1*1: With VSA system

NOTE:
· Connector with male terminals (double outline): view from terminal side
· Connector with female terminals (single outline): view from wire side
**: Connector with female terminals (single outline): view from terminal side

ECM Circuit Diagram (cont'd)

L12A4, L13A6 engines (LHD model)

1DASHBOARD
WIRE HARNESS2345678910121314151617ENGINE
COMPARTMENT
WIRE HARNESS111819202122FRONT SIDEBACK SIDE

232425262728DASHBOARD
WIRE HARNESS

3P CONNECTOR (1)14P CONNECTOR
(2)GAUGE B (3)GAUGE A (4)IGNITION SWITCH
(5)YAWRATE/LATERAL
ACCELERATION
SENSOR (10)*1SERVICE CHECK
CONNECTOR (6)DATA LINK
CONNECTOR (7)^**SECONDARY HO2S
(SENSOR 2) (8)FUEL PUMP (9)BRAKE PEDAL
POSITION SWITCH
(12)UNDER-DASH
FUSE/RELAY BOX (15)UNDER-DASH
FUSE/RELAY BOX (16)UNDER-DASH
FUSE/RELAY BOX (17)UNDER-DASH
FUSE/RELAY BOX (18)PGM-FI MAIN
RELAY 1 (13)^**PGM-FI MAIN
RELAY 2 (14)^**UNDER-DASH
FUSE/RELAY
BOX (20)UNDER-DASH
FUSE/RELAY
BOX (21)20P CONNECTOR (23)ECM CONNECTOR
No. 1 (9P) (24)^**16P CONNECTOR (22)*112P JUNCTION
CONNECTOR (11)ECM CONNECTOR
No. 3 (52P) (25)^**ECM CONNECTOR
No. 5 (9P) (27)^**INERTIA SWITCH
(28)ECM CONNECTOR
No. 4 (40P) (26)^**UNDER-DASH
FUSE/RELAY
BOX (19)*1: With VSA system

NOTE:
· Connector with male terminals (double outline): view from terminal side
· Connector with female terminals (single outline): view from wire side
*: Connector with female terminals (single outline): view from terminal side
