Danger/Warning/Caution Label Locations
Danger/Warning/Caution Label Locations
NOTE:
- The illustration shows the LHD model; RHD model is symmetrical.
- SIDE AIRBAG INFORMATION located on the driver's and passenger's doorjamb.
Passenger's Compartment:
SIDE AIRBAGINFORMATIONSTEERING
COLUMN NOTICEFRONT SEAT BELT
TENSIONER WARNINGMONITOR CAUTIONSIDE AIRBAG MODULE DANGERFRONT PASSENGER
MODULE DANGERPASSENGER AIRBAG
CHILD SEAT CAUTIONAIRBAG CAUTION
Steering Wheel:
CABLE REEL CAUTIONDRIVER MODULE DANGERNOTE: The illustration shows the LHD model; RHD model is symmetrical.
SRS WARNINGENGINE COOLANT INFORMATIONBATTERY DANGERRADIATOR CAP DANGERAIR CONDITIONING INFORMATION
TYRE INFORMATIONPASSENGER AIRBAG CHILD SEAT CAUTIONDriver's Doorjamb:Passenger's Doorjamb:
