EPS Component Location Index (Except HATC Model)

EPS Component Location Index



TIE-RODS
Tie-rod Ball Joint Boot Replacement, EPS CONTROL UNIT
EPS Control Unit Replacement,
STEERING GEARBOX
Steering Gearbox Removal,
Steering Gearbox Overhaul,
Rack Guide Replacement, SERVICE CHECK CONNECTOR (2P)BATTERYDATA LINK CONNECTOR (16P)GAUGE ASSEMBLYUNDER-DASH
FUSE/RELAY BOXUNDER-HOOD
FUSE/RELAY BOXTORQUE SENSOR*: The illustration shows LHD model.
