Climate Control System Component Location Index #2

Climate Control System Component Location Index #2



A/C PRESSURE SWITCHRADIATOR FAN RELAY
CONDENSOR FAN RELAY
COMEPRESSOR CLUTCH RELAY
(Located in the under-hood fuse/relay box)
Test,
in the '02 Jazz/Fit Shop ManualOUTSIDE AIR TEMPERATURE SENSOR
Replacement,
Test, CONDENSER FANRADIATOR FANBLOWER MOTOR RELAY
(Located backside of the
under-dash fuse/relay box)
Test,
in the '02 Jazz/Fit Shop Manual
