Relay and Control Unit Locations - Dashboard #3 (RHD)

Relay and Control Unit Locations - Dashboard #3

RHD type:

ECM/PCMLEFT SUPERLOCKING RELAY (KE model) Wire colors:GRN/RED, BLK,
BLK, WHT and BLU/YELRIGHT SUPERLOCKING RELAY (KE model) Wire colors:GRN, BLK, BLK,
WHT and RED/WHT
