Rear Wheel Cylinder Disassembly/Inspection

Rear Wheel Cylinder Disassembly/Inspection

NOTE:

• Do not spill brake fluid on the vehicle; it may damage the paint; if brake fluid does contact the paint, wash it off immediately with water.

• To prevent dripping, cover disconnected hose joints with rags or shop towels.

• Clean all parts in brake fluid and air dry; blow out all passages with compressed air.

• Before reassembling, check that all parts are free of dust and other foreign particles.

• Replace parts with new ones whenever specified to do so.

• Make sure no dirt or other foreign matter is allowed to contaminate the brake fluid.

• Do not reuse the drained brake fluid.

• Use only clean Genuine DOT 3 Honda brake fluid. Non- Honda brake fluid can cause corrosion and shorten the life of the system.

• Do not mix different brands of brake fluid as they may not be compatible.

• Coat the piston, piston cup, and wheel cylinder bore with clean brake fluid.

• Make sure no grease or oil gets on the linings or drums.

• Replace all rubber parts with new ones whenever disassembled.

• Cylinder I.D. 15.87 mm (0.625 in) type (KQ, KU and KT models); Do not replace only a single unit of the piston cup by removing it from piston. Replace as the piston assembly.
