Relay and Control Unit Locations - Dashboard #1 (LHD)

Relay and Control Unit Locations - Dashboard #1

LHD type:

KEYLESS RECEIVER UNITPOWER WINDOW RELAYTAILLIGHT RELAYBLOWER MOTOR RELAYA/T REVERS RELAYSTARTER CUT RELAY
(CVT)POWER DOOR
UNLOCK RELAYPOWER DOOR
LOCK RELAYPOWER MIRROR
DEFOGGER RELAYPGM-FI MAIN
RELAY2PGM-FI MAIN
RELAY1
