Immobilizer System Component Location Index (Except KH)

Immobilizer System Component Location Index



NOTE: LHD type is shown, RHD type is similar.IMMOBILIZER INDICATOR LIGHTECM/PCMINERTIA SWITCH
(KG, KR and KE models)IMOES UNIT
Input Test, IMMOBILIZER CONTROL UNIT-RECEIVER
Troubleshooting,
Replacement, IGNITION KEY
(Master and valet keys)TRANSPONDER
(Built into the ignition key)
